Concertina Razor Wire

Concertina razor wire is usually made of galvanized steel blade or stainless steel blade. Two pieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The spiral intersecting barbed wire presents an intersecting shape after opening with beautiful outlook and practical property.

Material for Concertina razor wire: Galvanized steel or Stainless steel.
Features: Compact and rational structure, high safety factor, for the protection of prison and key projects.
Technical note: Concertina razor wire can be made according to the actual dimension of customer.

Razor barbed wire fencing and razor wire concertina makes the majority of our products. Razor barbed wire fencing is usually made of galvanized steel blade or stainless steel blade. Two pieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The spiral intersecting barbed wire presents an intersecting shape after opening with beautiful outlook and practical property.

Concertina Razor Wire security Fencing

38" in diameter are fabricated from 0.020" thick,galvanized steel strip.
Strip is clinched around a galvanized steel core wire.
Each roll consists of 56 coil loops with pairs of coil loops alternately clipped together at five locations around the circumference.
Each coil extends to 50' when deployed at 21" coil spacing.

Concertina Single Coiling razor wire is installed without clips; it runs in natural loops on walls or fencings. Single coiling razor wire is costless and can be easily installed.

Material: high quality and low in carbon steel and stainless steel band.
Type: straight razor wire, spiral blade gill nets, flatbed blade gill nets.

Concertina Cross razor wire is crossed razor wire. Two pieces of stainless steel razor wire or Zinc-coated Wire are bound together by clips to make it stronger.The spiral intersecting barbed wire presents an intersecting shape after opening with beautiful feature and practicality.

listing:

Single Electric Galvanzied CBT-60 Concertina Barbed Razor Wire;
Single Coil spiral Concertina Razor Wire-stainless steel single coils straight line Concertina;
Galvanized Cross Type Razor Wire Cbt 60, Cbt65 Stainless Steel Razor Barbed Wire;
Stainless Steel Cross Razor Barbed Concertina Wire Coil.

BTO CBT Concertina Razor Barbed Wire

Hot Dipped Galvanized Razor Concertina Barbed Wire

450mm Coil Diameter Concertina Fencing Razor Barbed Wire

Blade Specification Blade Forms Blade Thickness Core Wire Dia. Blade Length Blade Width Blade Space
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 26±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5 28 15 45±1
BTO-30 0.5±0.05 2.5 30 18 45±1
CBT-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 100±
